A200

Active

Passionated with sound

Be ready to take the step into next generation of sound with AirPulse. Our state of the art research and development team are made of the most brilliant minds in audio engineering. The AirPulse brand sepecializes in top tier home.

The A200 is a feast to your eyes with its beautiful natural wood grain cabinet. It is most importantly, but not surprisingly, a feast to your ears. It accurately reproduces music with pure and extended high frequency, detailed and full mid range, and solid bass notes. The A200 is our latest gift to the most discriminating audiophiles and music lovers. It will bring you to a whole new level of listening experience, and you will fall in love with yourr favorite music all over again.

PHRASE CORRECTION HORN LOADED RIBBON TWEETER

The A200 horn loaded tweeter inherits the mechanism of the tweeter in our flagship 7001 near field monitor, but with an added phase correction device which greatly improves frequency response and increases sound dispersion. The A200 ribbon tweeter has a very low resistance of about 0.2 Ohm and it works with a transformer. The low resistance brings more current through the ribbon thus rise the SPL of high frequency, which leads to wide frequency response. We construct the A200 tweeter with the highest quality aluminum ribbon, strong Neodymium-Rare Earth magnets material coupled with an appropriate transformer to give it high sensitivity, superb transient response, extended frequency range and ultra high definition. The unique shape and size of the horn on the A200 tweeter was designed from precision calculation and simulation. Connecting the ribbon tweeter to a horn helps the sound generated by ribbon better coupled to the air. It further increased efficiency, power handling, frequency response and dispersion.

5.5” Aluminum cone low distortion mid-woofer

The 5.5" woofer in the A200 is an aluminum cone/large voice coil signature Phil Jones design. It uses a neodymium motor to provide a high magnetic flux to cover the entire voice coil of the loudspeaker. This is rarely done in speaker construction because of the sheer cost. Majority of loudspeakers use a voice-coil mostly overhung outside the magnetic field . By using a much larger magnetic field in the A200 woofer, we considerably reduce harmonic and inter-modulation distortion, giving the speaker a far more musical and natural sound. The Proprietary Aluminum Alloy Cone ( PAAC) was designed from painstaking analysis of all types of cone geometry and materials using a Klippel Laser Doppler Interferometer: A precision scientific measuring instrument that analyses cone behavior in 3D environment. The voice coil in A200 woofer is unconventionally larger than most 5.5" loudspeakers. Larger voice coils have less power compression because they run at a cooler operating temperature. Sonically this means a more realistic dynamic representation of the music. It is dynamics in music that gives it emotion and exhilaration. The cooler running temperature of the voice coil also brings a benefit of reliability and extremely rare driver failure. Most loudspeakers use round copper wire in the voice coil. The A200 uses a far better single layer edge-wound copper clad aluminum ribbon. Ribbon voice-coil wire gives more electrical conductor in the magnet gap and increases efficiency, power handling and lowers distortion. For optimum performance without compromise, the A200 woofer uses a hyper-rigid cast-magnesium alloy frame. Its increased rigidity greatly reduces speaker coloration, and its material helps to dissipate heat efficiently from the voice coil much faster than a typical steel speaker frame, all of which lead to increased dynamics and power handling and ultimately, a much more satisfying musical experience.

Full digital amplifier

The amplifier section of the A200 Is composed of three pieces of TAS5754 Class D ampliflers. Two are connected in parallel bridge mode to drive the left and right woofers, and one is connected in bridge mode for the two tweeters. Not like normal Class D amplifier, these amplifiers feature closed-loop structure with even lower distortion. Its digital input accepts signal with up to 192KHz sample rate. Its Hybrid-Flow digital processing enrich the system processing capability even more.

Other Features

Internal Wiring Made By Transparent
High Efficiency Switch Mode Power Supply
Two Digital Inputs Supports Up To 192khz
DSP Based Electronic Crossover
Two Analog Inputs with High Quality ADC
Bluetooth 4.0 Aptx Decoder

Specififations

Power
L/R(Treble)10W + 10W, L/R(Min-Range and Woofer) : 55W + 55W
Tweeter
Phase Correction Horn Loaded Ribbon Tweeter
Cabinet Size (WxHxD)
203 x 355 x 295 (mm)
Gross Weight
22.7Kg(50lbs)
Mid-Woofer
L/R(Treble)10W + 10W, L/R(Min-Range and Woofer) : 55W + 55W
Input Sensitivity
Balance Input 1000±50mV,AUX Input 550±50mV,Bluetooth Input 1000±50mFFs,Optical Input 350±50mFFs,Coaxial Input 350±50mFFs
Input Interface
AUX, Balance Input, Optical, Coaxial, Bluetooth
Net Weight
19 Kg(42lbs)
Signal-Noise Ratio
L/R:≥90dB(A)
Frequency Response
46Hz-20KHz
